ISELI SAA Fully Automatic Stellite Tipping Machine for Equipping Saw Teeth
ISELI SAA FULLY AUTOMATIC STELLITE TIPPING MACHINE FOR EQUIPPING SAW TEETH
-
HIGHLIGHTS BNA 100
• Equipment for annealing with a high-frequency generator
• Operation by touch screen
• Ventilation for dust exhaust
• 5 insets for stellite (alternative)
• 2 clamping jaws for formed-stellite
• Central height adjustment for saw blades
• 1 set of Tools
-
TECHNICAL DATA 100
• Blade thickness: 0,8 - 3,2 mm
BAND SAW
• Tooth pitch: 13 - 115 mm
• Blade length standard: from 5'500 mm
• Blade length optional: from 4'700 mm
• Blade width standard: 80 - 360 mm (70 mm bis Zahngrund)
CIRCLE SAW
• Diameter: Ø 250 – 1200 mm
• Bore: Ø 22 – 210 mm
GANG / FRAME SAW
• Tooth length: up to 1500 mm
• Blade Width: 80 - 180 mm
-
OPTIONS
• Optical monitoring of annealing temperature
• Device for control of the welding current
• Equipment for the band, circular and gang saw blades
• Equipment for double-toothed (twin cut) saw blades
• Loading system
-
