PRINZ  |  SKU: MOBILE-CUT-HIGH-TOP-LINE

PRINZ MOBILCUT HIGH LINE / TOP LINE

Shipping calculated at checkout.

Delivery and Shipping

Smith Sawmill Service ships to the Contiguous United States for orders from the website and typically ships products the same day during business hours. Weekend orders are processed the next business day. Products that are backlog or custom orders will be processed as soon as possible. Equipment deliveries vary based on current backlog and will be confirmed at time of order.  Please call 800-598-6344 for an estimate for equipment and shipping questions.

Description

PRINZ MOBILCUT STATE LINE

  • DESCRIPTION

    The MOBILCUT HIGH LINE completes the MOBILCUT range with this model equipped with an electric feed for cut and a user-friendly joystick lever.

    For enhanced working comfort, the MOBILCUT TOP LINE includes a saw positioning with an electric drive. More performance and ease of work!

    Main facts about the MOBILCUT STATE LINE :

    • motor power 11 kW

    • very robust guide arch

    • to cut packages up to 51″ x 51″ (130 x 130 cm) and 236″ (6 m) length

    • reduced space requirement with only 299″ (7,6 m) length

    • cut accuracy of +/- 0.08″ (±2 mm) with arch guiding

    • electric feed for cutting, control by joystick

    • with digital readout of the length

  • TECHNICAL DATA - MOBILCUT HIGH LINE

    Power:
    11 kW
    Motor / engine:
    electric
    Cutting accuracy:
    +/- 0.08″ (±2 mm)
    Standard package size (width x height)
    51″ x 51″  (130 x 130 cm)
    Larger dimensions available:
    yes
    Cut feed: electric
    Guiding of the cut:
    with arch
    Saw type:
    saw moves/stationary package
    Chain types:
    scraper chain/ carbide tipped chain
    Guide bar:
    solid steel, special hard-faced edge
    Cutting performance:
    1,8 min/m²
    Package/saw drive:
    positioning of the saw manually means of a handwheel
    Measuring device included
    Applications:
    traveling saw to handle packages up to 6m length with a cut accuracy of ±2mm and limited space requirement
    Options:
    laser light for cut position

    conveyors for waste removal

    connection for dust extraction

    container for waste removal

    TECHNICAL DATA - MOBILCUT TOP LINE

    Power:
    11 kW
    Motor / engine:
    electric
    Cutting accuracy:
    +/- 0.08″ (±2 mm)
    Standard package size (width x height)
    51″ x 51″  (130 x 130 cm)
    Larger dimensions available:
    yes
    Cut feed: electric
    Guiding of the cut:
    with arch
    Saw type:
    saw moves/stationary package
    Chain types:
    scraper chain/ carbide tipped chain
    Guide bar:
    solid steel, special hard-faced edge
    Cutting performance:
    1,8 min/m²
    Package/saw drive:
    positioning of the saw electrically (eight lengths programmable)
    Measuring device included
    Applications:
    traveling saw to handle packages up to 6m length with a cut accuracy of ±2mm and limited space requirement
    Options:
    laser light for cut position

    conveyors for waste removal

    connection for dust extraction

    container for waste removal
  • ARCH GUIDE FRAME VIDEO
