ISELI BNP 100 Automatic Profile Bandsaw Blade Sharpening Machine

by ISELI Swiss Precision
SKU ISELI-BNP-100

ISELI BPN 100 MACHINE FOR AUTOMATIC PROFILE SHARPENING OF BAND SAW BLADES CONTROLLED WITH 2 CNC AXES IN WET GRINDING

  • HIGHLIGHTS BPN 100

    The Iseli BNP100 Grinding Machine is a CNC-controlled sharpening machine BNP100 for band saw blades with a wheel diameter of 350 mm.

    • Powerful water cooling system with fully enclosed protection hood

    • Driven by servo motors

    • Use of linear roller guides (stiffer engineering and significantly increased lifetime)

    • Central blade height adjustment by electric control

    • Tooth shapes CNC controlled by X and Y-axis

    • Tooth shapes retrievable from the control unit (standard memory for 99’999 tooth shapes)

    • Metric or imperial measurement system selectable (mm or inch)

    • Operation by colored touch screen

    • Pneumatic saw blade clamping

    • Corundum grinding-wheel Ø 350 / 10 x 32 mm

    • 1 set of Tools / 1 cleaning kit

    GRINDING PROGRAMMES BNP 110

    iseli GRINDING PROGRAMS BNP 110, Smith Sawmill Service

    • Grinding program for standard toothing

    • Grinding program for vario toothing

    • Grinding program for winter toothing

  • TECHNICAL DATA

    • Tooth shape: Freely Programmable

    • Tooth Pitch: 10 - 100 mm (variant 1)

    • Tooth Height: up to 30 mm (variant 2)

    • Front Rake Angle: 0° - 35°

    • Blade Width Standard: 75 - 360 mm

    • Blade Width Option: 25 - 360 mm

    • Blade Length Standard: from 5300 mm

    • Blade Length Option: from 4300 mm

    • Grinding Wheel: Ø 350 mm

    • Grinding Wheel Bore: Ø 32 mm

    • Grinding Wheel Motor: 2,2 kW

    • Power Requirements: 400V 3Ph N, 50Hz, 4,2kVA

    • Air Connection: 6 bar

    • Coolant tank: 150 l

  • OPTIONS

    • CNC controlled dressing device

    • Electrically controlled cutting angle regulation

    • Grinding mist exhaust

    • Oil cooling with fire protection and air purifier

    • Lateral support, single stands, auxiliary back feed, loading system for band saw blades

    • Equipment for double toothed band saw blades

    • Several grinding programs (Vario, tooth height difference, 4 grinding speeds)

    • Tooth shape construction program “Tooth Shape Studio 3.0"

    • Remote maintenance
